PVC-C J41F-10V Flange Type Globe Valve DN15-150 GB Standard

PVC-C J41F-10V Flange Type Globe Valve DN15-150 GB Standard

PVC-C LABIUM Type Globe Valvae Rectus per Maximum Temperature DN15-DN150 Plastic Valvae Chemical Et Industrialis Ritus
Exemplar Number：J41F-10V
Materia: Plastic
Connection Form: Flange
Modus incessus: Manual
Pressura nominal: 10kg
Channel: Recta per Type
Structura: fixa Ball Valve
Type: fixa Ball Valve
Munus: bypass-Valve
Temperatus: High Temperature
Application: Industrial Ritus, Aquae Industrialis Ritus
Trademark: KXPV
Formularium: DN15-DN150
Origin: Ningbo, Zhejiang

Pressura Classis: 1.0Mpa（10bar）

Contact Us
PREV：PVC-U J41F-10U Flange Type Globe Valve DN15-150 GB Standard
DEINDE：Nullus proximus articulum
Product Features structuralis

1. Corpus plasticum egregium corrosionis resistentiae et abrasionis resistentiae habet.
2. Compact consilium, quale et vile.
3. Plectrum fluxus subtilis ordinatur expers.

App Temperature Bound List

Materia Medium temperatura Materia Medium temperatura
PVC-C -20℃~ 95℃ PVC-U -5℃~ 45℃
FRPP -20℃~ 120℃ PPH -20℃~ 110℃
PVDF 40℃~ 150℃

Pars Materia Tabula

Nec.

Nomen

Materia

1

Rota

Alloy materia

2

sigillum nucis

FRPP, PVDF, PVC-C,PVC-U,PPH

3

Sigillum caulis

PTFE

4

Cap nut

FRPP

5

Sexangulus nut

Chalybe, immaculata ferro

6

implens plece

Chalybe, immaculata ferro

7

Bonnet

FRPP, PVDF, PVC-C,PVC-U,PPH

8

Duplex praevenirent

Chalybe, immaculata ferro

9

Stem

Steel Plastic

10

Capping

FRPP, PVDF, PVC-C,PVC-U,PPH

11

Corpus

FRPP, PVDF, PVC-C,PVC-U,PPH

12

Flexilis washer

EPDM,FPM

13

Sexangulus nut

Chalybe, immaculata ferro

14

Cap nut

FRPP

Flange Type Globe Valvae Conventus Detail Drawing

Dimension List

DN (mm)

D1

D2

H

L

T

n-Φ

GB

JIS

ANSI

GB

JIS

ANSI

15(1/2")

105

65

70

2.38

220

154

18

4-Φ14

4-Φ15

4-Φ16

20 (3/4")

105

75

75

2.76

220

154

18

4-Φ14

4-Φ15

4-Φ16

25 (1)

115

85

90

3.13

220

160

20

4-Φ14

4-Φ19

4-Φ16

32 (11/4")

135

100

100

3.45

250

185

20

4-Φ18

4-Φ19

4-Φ16

40 (11/2")

150

110

105

3.88

275

200

20

4-Φ18

4-Φ19

4-Φ16

50 (2)

165

125

120

4.74

350

230

20

4-Φ18

4-Φ19

4-Φ19

65 (21/2").

185

145

140

5.49

390

295

24

4-Φ18

4-Φ19

4-Φ19

80 (3).

200

160

150

6

400

310

25

8-Φ18

8-Φ19

4-Φ19

100 (4")

220

180

175

7.5

410

350

26

8-Φ18

8-Φ19

8-Φ19

125 (5).

250

210

210

8.5

430

400

30

8-Φ18

8-Φ23

8-Φ22

150 (6)

285

240

240

9.51

480

480

33

8-Φ23

8-Φ23

8-Φ22
